Yoshino Metal System Ceiling 35

Yoshino Metal System Ceiling 45

Note For Installation:

  • The connector clip of Yoshino Metal System Ceiling frame system, an indentation formed for easier lock to the channel and make the system sturdy
  • All gypsum board joints must be staggered
  • Pay attention to the installation of the connector clip. The part where the indentation remain should be installed on the open part (as in the picture)
  • It is recommended to use control joint every 10 meters
  • The frame distance is 1200, the lower frame is 600 and the hanger distance is 1200
  • Standar Yoshino Metal System Ceiling Berdasarkan ASTM 840 – 11
